Forum ISO 13628-8 Class 1-4 (API 17D) Surface

This unit is used to give pre-dive surface confirmation of the torque tool calibration. It consists of a standard ISO class 1-4 torque reaction bucket with sturdy base and built in torque sensor. The unit comes complete with USB cable to connect to torque tool control system for auto calibration.

• ISO 13628-8 fig 18 (API 17D) class 1-4
• Max torque 2700Nm / 2000ft lbs
• Hand held digital read out
• USB output to torque tool control system
• Includes easily interchangeable shafts to suit full range
• Configured for 17H and Petrobras

• Surface torque tool calibration
